Finex Tumbling Machine is engineered for efficient and uniform mixing, coating, polishing, and conditioning of powders, granules, and small solid components. Designed with precision and durability, it ensures consistent product quality with gentle handling, making it ideal for industries requiring homogeneous blending without particle damage.
The machine operates on a rotating drum principle, where materials are continuously lifted and cascaded to achieve uniform distribution. Its robust construction, smooth internal finish, and optimized rotation speed provide high performance with minimal maintenance.
It is a unique simulation of hand screening by the eye. The mechanical simulation is achieved by the Tumbler screening machine which works on the principle of gyratory motion which enhances the horizontal motion of the plain sifter. The eccentricity speed can be varied to vary the residence time of the powder to be screened.
The three dimensional tumbling motion distributes the screening material over the entire surface of the screen. Gentle low frequency and high amplitude movement increases the screening efficiency without screen blinding. Ordinary motors are being used with pulleys to generate tumbling motion. Accessories such as top and bottom rotating brushes are offered to prevent screen blinding to take place.
| Models offered | ||
|---|---|---|
| Model no | Size | Motor |
| FSPL-TM-24 | 24 inch | 2 HP |
| FSPL-TM-36 | 36 inch | 2 HP |
| FSPL-TM-48 | 48 inch | 3 HP |
| FSPL-TM-60 | 60 inch | 5 HP |
| FSPL-TM-72 | 72 inch | 7.5 HP |
